H600A/B Mid-Tower


Key Features:
  • MicroATX/ATX super middle tower
  • Support 12”(305mm)x9.6”(244mm) ATX motherboard
  • Patented rail and screw 5.25” drive bays
  • Patented screwless front bezel
  • Front USB, Audio, 1394 support (option)
  • Better Expansion - 7 slots and a maximum of 4*5.25-inch and 6*3.5-inch drive bays
  • Complies with FCC Class B, DoC, and CE
  • Support 300W(ATX 12V) all safety power supply
Housing Material Metal: SECC
Main Board Size FlexATX/MicroATX/ATX/Full AT
12"(305mm) x 9.6"(224mm)/ATX M.B.
Disk Drive Bays 3.5" *2/1(external/internal)
5.25" *4/0(external/internal)
Power Supply 300W ATX 12V (ball bearing fan) high efficiency, UL/CSA/CE/VDE/S/D/N/ FI/FCC /DoC certified
Dimensions Width  7.87"(200mm)
Height 18.0"(457mm)
Depth 18.1"(460mm)
Front USB &Audio 2*USB / Head phone / Mic. In
Ventilation 8cm Optional DC fan x5(1 installed, 4 option)
FCC,CE Ready
Net Weight 20.0 lbs. /9.1 kg
Gross Weight 21.5 lbs. / 9.8 kg
Volume 2.5 Cu. ft.
