FireGL V3100

Features
  • Built on ATI’s native PCI Express x16 lane architecture
  • Outstanding entry-level workstation performance and quality utilizing 4 pixel pipelines and 2 geometry engines
  • 128 MB DDR unified graphics memory
  • Dual display support via DVI and VGA outputs
  • Optimized and certified for professional workstation applications based on OpenGL® and Microsoft® DirectX® 9.0
  • Windows® and Linux® support
  • Three year warranty with toll-free advanced technical support

PCI Express Innovation Has Arrived
The FireGL™ Visualization series of workstation graphics accelerators is designed specifically for the new, high-bandwidth PCI Express® bus, and is architected to deliver unprecedented speed and image quality for real-time visualization. True cinematic quality rendering of complex geometry is now available for compelling animation, visual effects, mechanical design and leading-edge business communication.

Two Way Acceleration With ATI’s Single-Chip PCI Express Solution
The bridgeless, single-chip design of the FireGL native PCI Express graphics processor fully engages all of the benefits of this interconnect standard in the safest, most cost effective, and most reliable transition from AGP. Unlike other ‘bridged’ PCI Express implementations, ATI’s FireGL PCI Express products deliver full bandwidth in both upstream and downstream directions, doubling the capabilities of previous products.

Compatibility And Stability
ATI’s FireGL cards — whether PCI Express x16 lane or AGP 8X — are designed to accelerate 3D workstation applications based on OpenGL® and Microsoft® DirectX® 9.0. With full certification on the leading computer aided design (CAD), architecture/engineering/ construction (AEC) and digital content creation (DCC) applications, FireGL is the high performance choice for graphics professionals working in Windows® or Linux® based systems.

Technical Specifications

Graphics technology

  • Powered by ATI’s scalable FireGL workstation Visual Processing Units (GPU)
  • Up to 256-bit high bandwidth memory architecture
  • 2, 4 or 6 parallel geometry engines
  • 4, 8 or 16 parallel pixel pipelines
  • 128-bit full floating point precision
  • 24-bits per RGBA component displays beyond 16.7M colors

Display support

  • Dual DVI-I supports any combination of digital and analog displays1
  • Maximum resolution of 2048x1536 per display (dual mode)
  • 3840 x 2400 support (dual link2)
  • Independent resolution and refresh rate selection for any two connected displays
  • Dual integrated 10-bit per channel 400 MHz DACs
  • Integrated 165 MHz TMDS transmitter (DVI & HDCP compliant)

API and Operating system support

  • OpenGL® 1.5 + extensions
  • OpenGL Shading Language
  • Microsoft® DirectX® 9.0
  • DX9 HLSL
  • Windows® XP/Windows XP64/Windows 2000
  • Linux® 32/Linux 64

Graphic Features

Hardware acceleration of the following:

  • Anti-aliased points and lines or full scene anti-aliasing (2X, 4X, 6X)
  • 3D lines and triangles
  • Stipple points
  • Two-sided lighting
  • Up to 8 light sources
  • Directional and local lighting
  • OpenGL overlay planes
  • Occlusion culling
  • 6 user defined clip planes
  • OpenGL polymode functions
  • 32-bit (24+8-bit stencil) Z Buffer
  • Fast Z and color clears
  • Full DX9 vertex shader support with up to 6 vertex units
  • Quad-buffer stereo support 3

SmartShader™ Technology

  • Programmable pixel and vertex shaders
  • 16 textures per pass
  • Pixel shaders up to 160 instructions with 32-bit floating point precision for each RGBA component
  • Multiple render target support
  • Shadow volume rendering acceleration
  • High precision 10-bit per channel frame buffer support

SmoothVision™ Technology
  • 2X/4X/6X anti-aliasing modes
  • High performance adaptive algorithm with programmable sample patterns
  • 2X/4X/8X/16X anisotropic filtering modes
  • Adaptive algorithm with bi-linear (performance) and tri-linear (quality) options

HyperZ™ Technology
  • 3-level Hierarchical Z-Buffer with early Z test
  • Lossless Z-Buffer compression (up to 24:1)
  • Fast Z-Buffer Clear

System requirements
  • Intel® Pentium® 4/Xeon™, AMD Athlon®/Opteron™ or compatible CPU
  • PCI Express bus4
  • AGP 8X/4X bus5
  • 128MB of system memory (256MB or more recommended)
  • Installation software requires CD-ROM drive
  • 300 watt or greater power supply (recommended)

1. All FireGL boards have dual DVI-I connectors except FireGL T2-128 and FireGL V3100 which have one DVI-I and one VGA connector.
2. Dual link available on FireGL X3-256, FireGL V5000, and FireGL V7100 only (on second DVI port)
3. Stereo 3D available on FireGL X3-256, FireGL V3200, FireGL V5000, FireGL V5100 and FireGL V7100.
4. FireGL Visualization series supports PCI Express x16 lane bus.
5. FireGL T2-128, FireGL Z1-128, FireGL X1-128, FireGL X2-256t and FireGL X3-256 support AGP 8X bus.
