| CPU: |
- Supports Socket A for AMDŽ Athlon(tm)/Athlon(tm)
XP/Duron(tm) Processor
- Supports up to Athlon XP 3000+ processor
|
| Chipset: |
- VIAŽ KM400 Chipset
- FSB @200/266/333MHz
- Integrated S3 Graphics UniChrome 2D/3D Graphics with motion compensation
- AGP 4x and 8X
- Advanced memory controller supports PC2100 DDR266 technology.
- VIAŽ VT8235 Chipset
- Integrated Direct Sound AC'97 audio.
- Dual Channel Ultra DMA 33/66/100/133 master mode EIDE controller.
- Supports both ACPI and PC2001 compliant enhanced power management.
- 6 ports USB 2.0 controller.
- Integrated Ethernet MAC.
|
| FSB: |
|
|
| Main Memory: |
- Supports four memory banks by using two 184-pin DDR DIMMs
- Support upto 2GB of DDR200/266/333 DDR SDRAM.
- Supports 2.5v DDR SDRAM DIMM
|
| Slots: |
- One AGP (Accelerated Graphics Port) slot 1.5V 4X/8X slot.
- Three 32-bit PCI bus slots (Support 3.3V/5V PCI bus
interface)
|
| On-Board IDE: |
- An IDE controller on the VT8235 chipset provides IDE
HDD/CD-ROM with PIO, Bus Master and Ultra DMA 66/100/133 operation modes.
- Can connect up to four IDE devices.
|
| Video: |
- S3 Graphics UniChrome(tm) 2D/3D Graphics with motion
compensation
|
| Audio: |
- AC'97 link controller integrated in VIA VT8235.
- RealTek ALC655 6-channel audio.
- Compliance with AC'97 v2.3 spec.
- Meet PC2001 audio performance requirement.
|
| LAN: |
- VIAŽ Fast Ethernet LAN.
- with external VT6103 Fast Ethnernet PHY 10/100 Base-T LAN transformer.
- Integrated Fast Ethernet MAC and PHY in VT8235.
- Supports 10Mb/s and 100Mb/s auto-negotation operation.
- Compliance with PCI v2.2 and PC99 standard
- Supports ACPI power management.
|
| On-Board Peripherals: |
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M
and 2.88Mbytes
- 1 serial port (COM1), 1 VGA port
- 1 parallel port supports SPP/EPP/ECP mode
- 6 USB ports (Rear x 4 / Front x 2)
- 1 Vertial audio ports (Line-In/Line-Out/Mic-In port)
- 1 LAN RJ45 jack
|
| BIOS: |
- The mainboard BIOS provides "Plug & Play" BIOS
which detects the peripheral devices and expansion cards of the board automatically.
- The mainboard provides a Desktop Management Interface(DMI)
function which records your mainboard specifications.
|
| Dimension: |
- 24.4 cm(L) x 22.4 cm(W) MicroATX Form Factor
|
| Mounting: |
|
|
