• 12 in.(L) x 9.65 in.(W); ATX
• 4 DIMMs w/ DDR400 up to 4GB
• 1 AGP 8X; 5 PCI; 8 USB
• 8 Ch. Audio; Gb LAN; SATA; ATA100
• Live Update; Fuzzy Logic; PC Alert;
  MSI CoreCell; MSI CoreCenter, DOT

• Supports Intel® Pentium 4/Celeron D processors in LGA775 Package.
• Supports up to Pentium 4 5XX and Celeron D 3XX sequence processor
• Support Intel® Ø4B and Ø4A processors
• Support Intel® Hyper-Threading Technology
• Support 533/800MHz FSB

• Intel® 865PE Chipset
  - Supports FSB 800/533/400MHz
  - Supports AGP 8X interface
  - Supports DDR 400/333/266 memory interface

• Intel® ICH5 Chipset
  - Hi-Speed USB (USB2.0) controller, 480Mb/sec, 8 ports
  - 2 Serial ATA/ 150 ports
  - 2 channel Ultra ATA 100 bus Master IDE controller
  - PCI Master v2.3, I/O APIC
  - Supports both ACPI and legacy APM power management

• Supports four unbuffered DIMM of 2.5 Volt DDR SDRAM
• Supports up to 4GB memory size without ECC
• Supports Dual channel DDR266/333/400MHz and up.

• One AGP slot supports 8X/4X at 0.8V (AGP 3.0) or 4X at 1.5V (3.3V is not supported)
• Five 32-bit v2.3 Master PCI bus slots (support 3.3V/5V PCI bus interface)

• Dual Ultra DMA 66/ 100 IDE controllers integrated in ICH5
  - Supports PIO, Bus Master operation modes
  - Can connect up to four Ultra ATA drives

• Serial ATA/ 150 controller integrated in ICH5
  - Up to 150MB/s transfer speed
  - Can connect up to 2 Serial ATA drives

• Realtek® 8110S
  - Integrated Fast Ethernet MAC and PHY in one chip
  - Supports 10Mb/s, 100Mb/s, 1000Mb/s
  - Compliance with PCI 2.2
  - Supports ACPI Power Management

• AC97 link controller integrated in Intel® 865PE Chipset
• 8-channel audio codec Realtek ALC850
  - Compliance with AC97 v2.3 Spec.
  - Meet PC2001 audio performance requirement

• 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
• 1 serial port COM1
• 1 parallel port supports SPP/EPP/ECP mode
• 8 USB 2.0 ports (Rear x 4 / Front x 4)
• 1 Line-In / Line-Out / Mic-In audio port
• SPDIF Out-Optical audio port
• 1 RJ45 LAN jack

• The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
• The mainboard provides a Desktop Management Interface (DMI) function which records your mainboard specifications.

• ATX Form Factor: 30.5 cm (L) x 24.5 cm (W)

• 9 mounting holes
