K8N Neo3-F (Socket-754)

Special Features:
  • 11.61 in.(L) x 7.28 in.(W); ATX
  • 2 DIMMs w/ DDR 400 up to 2 GB
  • 1 PCI-E 16X; 1 PCI-E 1X, 1 AGR (Advanced Graphic Riser slot), 3 PCI; 10USB
  • 6 CH Audio
  • Gb LAN; RAID(0, 1, 0+1); SATA; ATA133
  • Live Update; Fuzzy Logic; PC Alert; MSI CoreCell; MSI CoreCenter; DOT;
    DigiCell; nVidia Firewall
CPU
  • Supports 64-bit AMD® Athlon™ 64 processor (Socket 754)
  • Supports 2800+, 3000+, 3200+, 3400+, 3700+
  • Supports Sempron 2600+, 2800+, 3000+, 3100+, 3300+
Chipset
  • NVIDIA ® nForce4-4X Chipset
    - HyperTransport link to the AMD Athlon 64 CPU
    - Supports DDR333/400 memory
    - Supports PCI Express x16/x1 interface
    - Two independent SATA controllers, for four drives
    - Dual Ultra ATA 133/100/66 IDE controllers
    - Supports high-speed USB2.0 ports
Main Memory
  • Supports single channel, using two 184-pin DDR DIMMs
  • Supports a maximum memory size up to 2GB
  • Supports 2.5v DDR SDRAM DIMM
    Due to the High Performance Memory design, motherboards or system configurations may or may not operate smoothly at the JEDEC (Joint Electron Device Engineering Council) standard settings (BIOS Default on the motherboard) such as DDR voltage, memory speeds and memory timing. Please confirm and adjust your memory setting in the BIOS accordingly for better system stability.
    Example: Kingston HyperX DDR500 PC4000 operates at 2.65V, 3-4-4-8, CL=3.
    For more information about specification of high performance memory modules, please check with your Memory Manufactures for more details.
Slots
  • One PCI Express X16 slot (PCI Express Bus specification v1.0a compliant)
  • One PCI Express X1 slot (PCI Express Bus specification v1.0a compliant)
  • Three 32-bit Master 3.3V/5V PCI Bus slots
  • One AGR (Advanced Graphics Riser) slot
    The AGR slot is a special design that only supports compatible AGP VGA cards. For more detailed information on compatible AGP VGA cards, please refer here
On-Board IDE
  • Dual IDE controllers on the NVIDIA nForce4-4X chipset provides IDE HDD/CD-ROM with PIO, Bus Master and Ulra DMA 133/100/66 operation modes
  • Can connect up to 4 IDE devices
On-Board SATA
  • Supports 4 SATA ports with up to 150MB/s transfer rate
LAN
  • Marvell PHY 88E1111 Gigabit Ethernet chip
USB Interface
  • 10 USB ports
    - Controlled by nForce4 Ultra chipset
    - 4 ports in the rear I/O, 6 ports via the external bracket
NV RAID (Software)
  • Supports up to 4 SATA and 4 ATA133 Hard drives
    - RAID 0, 1, 0+1, or JBOD supported
    - RAID function available for ATA133 + SATA H/D drives
Audio
  • RealTek ALC655 6-channel software audio codec
    - Compliance with AC97 v2.3 spec.
    - Meets PC2001 audio performance requirement
On-Board Peripherals
  • 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
  • 1 serial port
  • 1 parallel port supports SPP/EPP/ECP mode
  • 10 USB2.0 ports (Rear x 4 / Front x 6)
  • 1 Audio (Line-In/Line-Out/MIC) port
  • 1 RJ-45 LAN Jack
  • 2 IDE ports support 4 IDE devices
  • 4 serial ATA ports
BIOS
  • The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
  • The mainboard provides a Desktop Management Interface (DMI) function which records your mainboard specifications.
  • Supports boot from LAN, USB Device 1.1 & 2.0 and SATA HDD
Dimension
  • 11.61 in (L) x 7.28 in(W) ATX Form Factor
Mounting
  • 6 mounting holes
