CPU |
- Supports 64-bit AMDŽ Athlon™ 64FX/64
processor (Socket 939)
- Supports 3000+ (D0), 3200+ (D0),
3500+, 3800+, 4000+, FX53 and FX55
|
Chipset |
- nVIDIAŽ nForce3 Ultra Chipset
- HyperTransport link to the AMD Athlon 64/Athlon 64FX CPU
- HyperTransport supporting speed up to 1GHz (2000MT/s)
- AGP3.0 8X interface at 533MT/s (million transfers per second)
- Two independent SATA controllers, for four drives
- IEEE 802.3 NVIDIA MAC for 1000BASE-T
- Dual Fast ATA-133 IDE controllers
|
Main Memory |
- Supports dual channel DDR
266/333/400, using four 184-pin DDR DIMMs.
- Supports the memory size up to 4GB
- Supports 2.5v DDR SDRAM DIMM
Due to the High Performance Memory design,
motherboards or system configurations may or may not operate
smoothly at the JEDEC (Joint Electron Device Engineering Council)
standard settings (BIOS Default on the motherboard) such as DDR
voltage, memory speeds and memory timing. Please confirm and adjust
your memory setting in the BIOS accordingly for better system
stability.
Example: Kingston HyperX DDR500 PC4000 operates at 2.65V, 3-4-4-8,
CL=3.
For more information about specification of high performance memory
modules, please check with your Memory Manufactures for more
details.
|
Slots |
- One AGP (Accelerated Graphics Port)
1.5V 4X/8X slot
- Five 32-bit v2.3 Master PCI bus
slots (support 3.3v/5v PCI bus interface)
|
On-Board IDE
& Serial ATA |
- An IDE controller on the nVIDIA
nForce3 Ultra chipset provides IDE HDD/CD-ROM with PIO, Bus Master
and Ultra DMA133/100/66 operation modes.
- Can connect up to 4 IDE devices
- Supports 4 SATA ports. Transfer rate
is up to 150MB/s
- NV RAID (Software)
- Support up to 4 SATA & 4 ATA133 Hard
drives
- RAID 0 or 1, 0+1, JBOD is supported
- RAID function work w/ATA133 + SATA H/D
|
LAN |
- Supports dual LAN jacks
- 1 LAN supports 10/100/1000 Fast Ethernet by Marvell 88E1111 PHY
- 1 LAN supports 10/100/1000 Fast Ethernet by Realtek 8110S
(1000Mbps)
|
IEEE 1394 |
- VIA 6306 chipset
- Supports up to 3 x 1394 ports
- Transfer rate is up to 400Mbps
|
Audio |
- 7.1 channel audio codec RealTek
ALC850.
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement.
|
On-Board Peripherals |
- 1 floppy port supports 1 FDD with
360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 1 serial port
- 1 parallel port supports SPP/EPP/ECP
mode
- 1 audio jack (5-in-1), coaxial/fibre
SPDIF out
- 8 USB 2.0 ports (Rear x 4 / Front x
4)
- 2 RJ45 LAN jack
- 3 IEEE 1394 connectors (Rear x 1/
Front x 2)
|
BIOS |
- The mainboard BIOS provides "Plug &
Play" BIOS which detects the peripheral devices and expansion cards
of the board automatically.
- The mainboard provides a Desktop
Management Interface (DMI) function which records your mainboard
specifications.
|
Dimension |
- 30.5cm(L) x 24.5cm(W) ATX Form
Factor
|
Mounting |
|
