| CPU |
- Supports 64-bit AMD® Athlon64/64FX
processor (Socket 939)
- Supports 3000+, 3200+, 3400+, 3500+,
3800+, 4000+, FX53 and FX55
|
| Chipset |
- ATI Radeon® XPRESS 200 Chipset
- HyperTransport connection to AMD K8 Athlon 64 processor
- 8 or 16 bit control/address. data transfer both directions
- 1000/800/400/200MHz "Double Data Rate" operation both direction
- PCI Express x16 Graphic Interface
- On-board Graphic shared up to 128MB
- ATI ® SB400 Chipset
- Ultra DMA 66/100/133 master mode PCI EIDE controller
- Supports dual channel native Serial ATA/RAID controller that will
supply 150MB/s and support RAID 0 or RAID 1
- Integrated Hardware Sound Blaster / Direct Sound AC97 audio
- ACPI & PC2001 compliant enhanced power management
- Supports 8 USB2.0 ports (Rear x 4 / Front x 4)
|
| Main Memory |
- Supports four 184-pin DDR SDRAMs up
to 4GB memory size
- Supports Dual Channel DDR400*/DDR333
DDR SDRAM (*Refer to MSI recommended modules)
- Support for 2Mx32 (with 64-bit
interface), 4Mx32, 8Mx32 and 16Mx16 memory devices
Due to the High Performance Memory design,
motherboards or system configurations may or may not operate
smoothly at the JEDEC (Joint Electron Device Engineering Council)
standard settings (BIOS Default on the motherboard) such as DDR
voltage, memory speeds and memory timing. Please confirm and adjust
your memory setting in the BIOS accordingly for better system
stability.
Example: Kingston HyperX DDR500 PC4000 operates at 2.65V, 3-4-4-8,
CL=3.
For more information about specification of high performance memory
modules, please check with your Memory Manufactures for more
details.
|
| Slots |
- One PCI Express 16X slot
- Three PCI 32-bit Master PCI Bus
slots. (support 3.3v / 5v PCI bus interface)
|
|
Video |
- 3D Graphics
- Full DirectX 9.0 Support (Vertex Shader v2.0 and Pixel Shader
v2.0) with full precision floating point pixel pipeline, up to 4
Multiple-Render-Targets (MRTs)
- Supports Microsoft's next generation GDI + user interface and
support resolution up to
2536 x 2536 @ 32bpp
- 2D Graphics
• Highly optimized 128-bit engine capable of processing multiple
pixels per clock
• Game acceleration including support for Microsoft's DirectDraw,
Double Buffering, Virtual Sprites, Transparent Blit, and Masked Blit.
• Supports a maximum resolution of 2048 x 1536 @ 32bpp
• Support for new GDI extensions in Windows® XP: Alpha BLT,
Transparent BLT, Gradient Fill
|
| On-Board IDE
|
- An IDE controller on the ATI SB400
chipset provides IDE HDD/CD-ROM with PIO, Bus Master and Ultra DMA
66/100/133 operation modes. It can connect 4 Ultra ATA drives.
- Serial ATA/150 controller integrated
in ATI SB400
- Up to 150MB/s transfer speed
- Can connect up to 4 Serial ATA drives
- Support RAID 0 or RAID 1
|
|
LAN |
- Realtek 8100C
- Supports 10/100 Mb/s
auto-negotiation operation.
- Compliant with PCI v2.2 and PC99
standard .
- Compliance with ACPI Power
Management
|
|
IEEE 1394 |
- Supports up to 2 x 1394 ports. one
6-pin 1394 connector on Rear I/O, the other is supported by onboard
Pin header. Transfer rate up to 400Mbps.
- Controlled by VIA 6307 chipset
|
| Audio |
- 6 Channel software audio codec
Realtek ALC658C
- Compliance with AC97' v2.3 Spec
- Meet PC2001 audio performance
requirement
|
| On-Board Peripherals |
- 1 floppy port supports 1 FDD with
360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 1 serial ports COM1
- 1 VGA port
- 1 parallel port supports SPP/EPP/ECP
mode
- 8 USB 2.0 ports (Rear x 4 / Front x
4)
- 3 audio ports in vertical (Line-out,
Line-in, MIC)
- 1 IEEE 1394 6pin out
- 1 RJ-45 jack
|
| BIOS |
- The mainboard BIOS provides "Plug &
Play" BIOS which detects the peripheral devices and expansion cards
of the board automatically.
- The mainboard provides a Desktop
Management Interface (DMI) function which records your mainboard
specifications.
|
| Dimension |
- 9.60 in.(L) x 9.60 in.(W) Micro-ATX
Form Factor
|
| Mounting |
|
|
