PROCESSORS

• AMD^® Athlon (K7) processors
  Full series of Athlon/Duron CPU including the future Athlon processors

CHIPSET

• SiS^® 735 System Chipset
• Super I/O and LPC - ITE8705F
• System Hardware Monitor: Built-in ITE8705
• LAN: MAC integrated in SiS735 & PHY on board (Optional)
• AC97 Audio Codec

MEMORY

• 2 DDR DIMM sockets and 2 DIMM sockets support (can not be used simultaneously)
  Two 184-pin DDR SDRAM (DDR200, DDR266) or
  Two 168-pin 3.3V SDRAM (PC100, PC133)
• Maximum: 1.0GB (DDR or SDRAM)

SYSTEM BIOS

• AMI 2MB Flash EEPROM
• Supports Plug and Play 1.0A, AMP 1.2, Multi Boot, DMI
• Full Support for ACPI revision 1.0 specification

I/O INTERFACE

• Supports Plug and Play function
• PS/2 keyboard and PS/2 mouse connectors
• Dual USB Ports and LAN connectors
• One - EPP/ECP mode parallel port
• Two - 16550 high-speed serial I/O ports
• Audio Ports (Line-in, Line-out, Mic-in, CD-in and game port)
• Dual PCI IDE interfaces - support four IDE devices (PIO mode 4, DMA Mode 2, Ultra DMA 33/66/100)
• Supports 360K~2.88M Byte, 3 Mode FDDs or LS120
• ATX Power Supply Connector
• ports, Headers and Others:
  - IrDA Cable header
  - Extra USB header
  - Two CD-In headers
  - Front Panel MIC/Line-out header
  - HDD LED, ACPI MSG LED, Reset Switch, Power Switch headers
  - CPU and Case Fan headers
  - Modem Ring Wake Up Header

RTC & BATTERY

• SiS^® 735 included 256 bytes of CMOS SRAM
• With CMOS SRAM hardware clear jumper

EXPANSION SLOTS

• 5 PCI slots, 1 4X AGP slot, 1 AMR slot

FORM FACTOR

• ATX (304mm*244mm), 4 Layers
