| Type of Camera |
| Type of Camera |
Compact digital camera with built-in flash and 4x Optical/3.2x
Digital/13x Combined Zoom |
| Image Capture Device |
| Type |
3.2 Megapixel, 1/2.5 inch type Charge Coupled Device (CCD) |
| Total Pixels |
Approx. 3.3 Megapixels |
| Effective Pixels |
Approx. 3.2 Megapixels |
| Lens |
| Focal Length |
5.8-23.2mm, f/2.6-5.5 (35mm film equivalent: 35-140mm) |
| Digital Zoom |
3.2x |
| Focusing Range |
NORMAL: 1.5 ft./45cm-Infinity
MACRO: 2 in.-1.5 ft./5-45cm (WIDE), 11.8 in.-1.5 ft./30-45cm(TELE) |
| Autofocus System |
9-point AiAF/1-point AF (Fixed to center)Manual Focus, AF Lock, AF-assist
Beam ON/Off, MF magnified display function available |
| Viewfinders |
| Optical Viewfinder |
Real-image 4x optical zoom viewfinder |
| LCD Monitor |
1.8 inch low-temperature polycrystalline silicon TFT color LCD |
| LCD Pixels |
Approx. 115,000 pixels |
| LCD Coverage |
100% |
| Aperture and Shutter |
| Maximum Aperture |
f/2.6-8.0 (W), f/5.5-8.0 (T) |
| Shutter Speed |
15-1/2000 sec; can be set in 1/3-stop increments in Manual and
Shutter-priority (Tv) Modes. |
| Exposure Control |
| Sensitivity |
AUTO: ISO 50/100/200/400 equivalent |
| Light Metering Method |
Evaluative, Center-weighted average, Spot**Metering frame with Spot mode
is center fixed. |
| Exposure Control Method |
Program AE, Aperture or Shutter-Priority AE, Manual |
| Exposure Compensation |
+/- 2 stops in 1/3-stop increments |
| ND Filter |
Not Available |
| White Balance |
| White Balance Control |
Auto, Pre-set (Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H) or
Custom |
| Flash |
| Built-in Flash |
Operation Modes: Auto*, Flash On*, Flash Off* Red-Eye Reduction is
available |
| Flash Range |
WIDE: 1.5-11.5 ft./45cm-3.5m
TELE: 1.5-7.2 ft./45cm-2.2m
MACRO: 11.8 in.-1.5 ft./30-45cm (W/T) (When sensitivity is set to Auto) |
| Recycling Time |
Approx. 15 sec. or less (battery voltage=3.15V) |
| Flash Exposure Compensation |
Not Available |
| Shooting Specifications |
| Shooting Modes |
Auto, Creative Zone (P, Tv, Av, M), Image Zone (Portrait, Landscape,
Night scene, Fast shutter, Slow shutter), Special Scene Modes (Foliage, Snow, Beach,
Fireworks, Underwater, Indoor, Kids & Pets, Night Snapshot), Stitch Assist, Movie |
| Photo Effects |
Off, Vivid, Neutral, Low Sharpening, Sepia and Black & White |
| Self-Timer |
Activates shutter after an approx. 2 sec. or approx 10 sec. delay, Custom
timer |
| Wireless Control |
Not Available |
| Continuous Shooting |
Approx. 2.3 shots/sec. |
| Image Storage |
| Storage Media |
SD memory card, MultiMediaCard |
| Print Order Format |
Design rule for camera file system Exif 2.2(JPEG) and DPOF (Version 1.1)
compliant |
| Image Recording Format |
Still: Exif 2.2 (JPEG)
Movie: AVI (Image data: Motion JPEG; Audio data: WAVE (Monaural)) |
| JPEG Compression Mode |
Normal, Fine, SuperFine |
| Number of Recording Pixels |
Still Image: 2048x1536 (Large), 1600x1200 (Medium 1), 1024x768 (Medium
2), 640x480 (Small)
Movie: 640x480, 320x240 or 160x120 |
| Number of Recordable Images |
| |
Small (S) |
Medium 2 |
Medium 1 |
| |
N |
F |
SF |
N |
F |
SF |
N |
F |
SF |
| File Size |
84KB |
150KB |
249KB |
170KB |
320KB |
570KB |
278KB |
558KB |
1002KB |
| MMC-16MB |
138 |
87 |
56 |
80 |
45 |
25 |
50 |
26 |
14 |
| SDC-128MB |
1117 |
711 |
460 |
651 |
372 |
211 |
411 |
216 |
121 |
| SDC-512MB |
4316 |
2746 |
1777 |
2517 |
1438 |
816 |
1589 |
838 |
471 |
| |
Large |
Movie |
| |
N |
F |
SF |
160 x 120 |
320 x 240 |
640 x 480 |
|
|
|
| File Size |
445KB |
893KB |
1602KB |
120KB |
330KB |
660KB |
|
|
|
| MMC-16MB |
33 |
16 |
9 |
107
sec. |
43 sec. |
22 sec. |
|
|
|
| SDC-128MB |
269 |
136 |
76 |
869
sec. |
355
sec. |
181
sec. |
|
|
|
| SDC-512MB |
1041 |
529 |
295 |
3,357
sec. |
1,373
sec. |
702
sec. |
|
|
|
Note: N=Normal F=Fine SF=SuperFine
Storage capacity varies depending on the scene or the subjects. This data is estimated
from Canon's standard shooting conditions. Figures for Movie Mode represent total capacity
of SD Memory Card. Individual clips are limited to 3 minutes (30 seconds maximum at 640 x
480 resolution). The values given above vary depending on the subject, shooting conditions
and shooting mode. |
| Playback Specifications |
| Playback Modes File |
Single, Index (9 thumb images), Normal Playback, Special Playback, Movie
Editing, Camera Sound Playback |
| Erasing Specifications |
| Erase Modes |
Still Images: Single Images, All Images Movies: Part of Movie, All of
Movie |
| Interfaces |
| Computer Interface |
USB (mini-B/PTP) |
| Video Out |
NTSC or PAL |
| Audio Out |
Monaural |
| Other |
SD memory card slot. Direct connection to Canon CP Printers and select BJ
Printers via camera's USB cable (no computer required). |
| Power Supply |
| Power Source |
1. Two Size AA Alkaline batteries
2. Two Rechargeable size AA NiMH batteries (Canon brand NB-2AH/NB-1AH)
3. AC Adapter Kit (ACK800) |
| Shooting Capacity |
AA NiMH: LCD On - Approx. 300 shots (CIPA Test Standard); LCD Off -
Approx. 800 shots |
| Playback Time |
AA Alkaline batteries Approx. 180 minutes (Under Canon's standard
conditions*1 with fully charged battery), AA NiMH batteries Approx. 300 minutes. |
| Physical Specifications |
| Operating Temperature |
32-104° F/0-40° C |
| Operating Humidity |
10-90% |
| Dimensions (W x H x D) |
3.57 x 2.52 x 1.51 in./90.7 x 64.0 x 38.4mm (Excluding protrusions) |
| Weight |
Approx. 6.35 oz./180g (camera body only) |
|
Note: Note: *1 Normal temperature (73° F/23° C). Shoot images at wide
angle and at telephoto end alternatively with 20 second intervals. Use flash at every
fourth shot. Turn camera off and on after every eight shots. LCD brightness setting by
Factory default. |
